Description
The KLD20K series of quick-operating electric valves are designed for applications that require rapid opening and closing, offering a reliable alternative to problematic solenoid valves. These motor-driven valves feature fast opening (1 second) and immediate closing, with a special plastic construction that is resistant to scaling and corrosion. They have a standard service life of 30,000 cycles and come with an IP67 protection rating, with an F-type option available.
Technical specifications include
Valve Type: Quick-operating electric valve
Size: DN15
Pressure: Maximum 0.6 MPa (PN6)
Flow: Varies with valve size and application
Medium Temperature: 0°C to 100°C
Ambient Temperature: -20°C to 45°C
These valves are suitable for water filling, instrument control equipment, and any situation where a fast-opening and closing valve is required. Dimensions and weights for different sizes are provided.
Applications
Demanding quick opening and quick closing
Replacing normal solenoid valve,particularly when solenoid valve can not work reliably
Water billing
Instrument-control equipment
Technical Parameters
| Series | Opera- Time | Working Voltage | Max Power | static current (DC5V) | Enclosure | Max Pressure (P1 as inlet, P2 as outlet) | Medium Temperature | Ambient Temperature | Humidity | |||
| KLD20K | ON-2S OFF-0S | 5V | 3W | IP67 0-15mA | F type <65mA | IP67 | F type | p1>p2 p1<0.6Mpa p2<0.3Mpa | 0°C-100°C | -20°C<t<45°C | IP67≤85% (non-condensing) F type＞85% | |
| 12V,24V | 4W | |||||||||||
| 110V,220V | 5W | |||||||||||
Main Components Diagram
Main Components
Parts | Material |
Actuator housing | PC alloy |
Valve body | PP+GF |
| Seal | Silicon rubber |
Dimension
 |  |
Connection Size(unit: mm)
| DN | D | d | A | L | H | L1 | L2 | L3 | W(kg) |
| DN15 | G1/2" | 36.5 | 15 | 60 | 95.5 | 33.5 | 51.5/61.5 | 70 | 0.25 |
Notes:Please contact us for other info
Wiring
B2, B3, BD3,KT2 are available
If the valve does not work for long term,please make sure that the valve is off.
The vent should face the earth .please remove the rubber seal before usage.
※Subject to technical changes
